BPM

EMag, Therm, Lab and Mechanical Modules of Motor-CAD are available for the design of Brushless Permanent-Magnet Motors (BPM).

The BPM motor type is selected using the Motor Type pull down menu.

See E-Magnetics for more details of the BPM-EMag calculations.

See Thermal for more details of the BPM-Therm calculations.

See Mechanical for more details of the mechanical calculations.

The main BPM view is shown below:
