Feature Creation in DesignModeler

In DesignModeler, you can create custom Geometry Builder features.



In addition to the common capabilities listed in Feature Creation Roadmap, DesignModeler supports the feature creation capabilities that follow. References in this table take you to topics in the ACT Customization Guide for DesignModeler.

TopicReference

Capabilities specific to DesignModeler

DesignModeler Feature Creation >

DesignModeler – API usage examples

DesignModeler APIs >

For comprehensive API and XML information, see the Ansys ACT API and XML Online Reference Guide.

In the API information, see these DesignModeler namespaces:

  • Ansys.ACT.Interfaces.DesignModeler

  • Ansys.ACT.Automation.DesignModeler

In the XML information, see these key XML elements:

<extension>

            <simdata>

                    <Geometry>
