Reports for Arrays

There are some differences in the Report setup for Arrays.

  1. The solution/matrix quantities are grouped by category. The entries in each category are listed according to their [A vector, B vector Index] order in the corresponding matrix.

For a non-rectangular cells, the display is also controlled by A and B vectors and indices.

  1. The existing "Filter" capability can help locate the desired quantity from the potentially very long list.
