Feedback Iterator in Use

The Feedback Iterator system attaches to the Workbench schematic like any other system.

In the following example, a Maxwell system provides heat loss data to aFluent system. Dropping the Maxwell setup cell onto the Feedback Iterator component results in the links shown:

The Feedback Iterator add-in functions the same way with all systems that participate in the Electromagnetics product two-way loose coupling (Maxwell and HFSS for sources and Fluent, Thermal, and Structural for targets).
