Ohmic Loss for an Eddy Current Solution

Ohmic loss is given by:

where:

• J is the current density.
• J* is the complex conjugate of the current density.
• s is the conductivity in siemens/meter.

Ohmic loss is used to compute the power loss in a structure (P=I²R).

For impedance boundaries, ohmic loss is given by:

where:

• w is the angular frequency, which is equal to 2pf. (f is the frequency at which source currents and voltages oscillate during the solution.
• s is the conductor's conductivity in siemens/meter.
• m_r is the conductor's relative permeability.
• m₀ is the permeability of free space, which is equal to 4p x 10–7 H/m.
• H_t is the tangential component of H on the impedance boundary.
• H_t* is the complex conjugate tangential component of H on the impedance boundary.

The ohmic loss density (p_o) is given by the following:

This loss is calculated from the conduction component of the current density:

For the sake of brevity, the ohmic loss density in the post processor is labeled as Ohmic Loss. The total ohmic loss (p_o) of an object or the whole arrangement can be calculated by integrating the ohmic loss density over a proper volume in the Field Calculator, as follows:
