Integration with Ansys Workbench after Ansys Electromagnetics Product Installation

If you want to integrate Ansys Electromagnetics Suite with Ansys 2024 R2 after installation, do the following:

1. From the Start menu, select Ansys EM Suite 2024 R2 > Modify Integration with Ansys 2024 R2.

2. In the Integration with Ansys 2024 R2 dialog box, ensure that the Yes radio button is selected, then click OK to complete the integration process. Then OK the information dialog.



You can confirm that Ansys 2024 R2 will interact with the Ansys Electromagnetics Electronics Desktop application via the Ansys Workbench Options dialog box, which shows the Electronics Desktop install path.

The Journal Recording Language option permits you specify the default journal recording language.

• The default language is IronPython. You can change the recording language to VB.
• Changes in the recording language option apply to any Ansys Electromagnetics desktop launched after the change.
• Any open Ansys Electromagnetics desktop will continue recording in the language that was in effect when it was launched.
